> For the complete documentation index, see [llms.txt](https://docs.sonoransoftware.com/llms.txt). Markdown versions of documentation pages are available by appending `.md` to page URLs; this page is available as [Markdown](https://docs.sonoransoftware.com/cad/api-integration/api-endpoints-v2/integration-panels/manifest-reference.md). # Manifest Reference Reference for Integration Panel definitions, UI nodes, bindings, styling, actions, search, sorting, and sounds. A panel definition is a JSON object stored at a stable `panelKey`. The definition controls presentation and behavior; state is stored separately per `serverId` and `instanceKey`. ## Definition | Property | Type | Required | Description | | --------------- | --------- | -------- | ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- | | `schemaVersion` | integer | Yes | Must be `1`. | | `key` | string | No | When present, must equal the route `panelKey`. | | `name` | string | Yes | Panel header name; maximum 80 characters. | | `icon` | string | No | Quasar or Font Awesome icon, such as `fas fa-lock`. | | `surfaces` | string\[] | No | Layout availability: any of `dispatch`, `police`, `fire`, or `ems`. An empty array hides the panel from Add Window; explicit live-map blip references still work. This is not an authorization restriction. | | `sounds` | object\[] | No | Up to 20 sound triggers. | | `body` | object\[] | Yes | Recursive UI nodes; maximum 200 root nodes. | ## Bindings | Binding | Value | | ------------- | --------------------------------------------------------------------------------------------------------------------- | | `$state.path` | Current instance state | | `$item.path` | Current item inside a `repeat` node | | `$inputs.id` | Current local control value, or the control's displayed `value` when untouched. Explicit empty strings are preserved. | | `$value` | New value emitted by the current control | Use a binding as the entire property value, such as `"value": "$item.locked"`. For text containing other words, use interpolation such as `"Fuel: {{item.fuel}}%"` or `"Active: {{state.summary.active}}"`. ## Node Types | Type | Main properties | Purpose | | ---------- | -------------------------------------------------------------------- | ---------------------------------------- | | `row` | `children`, `gap`, `align` | Horizontal layout that wraps as needed | | `column` | `children`, `gap`, `align` | Vertical layout | | `grid` | `children`, `minItemWidth`, `gap` | Responsive auto-fit grid | | `section` | `title`, `children`, `style`, `animation` | Card-like group | | `repeat` | `source`, `children`, `search`, `sort`, `layout` | Render state array items | | `text` | `text`, `variant`, `appearance` | Text; variants are `title` and `caption` | | `icon` | `icon`, `size`, `color` | Quasar or Font Awesome icon | | `badge` | `label`, `appearance` | Compact status chip | | `divider` | — | Separator line | | `spacer` | `size` | Vertical space in pixels | | `alert` | `text`, `appearance` | Highlighted message | | `input` | `id`, `label`, `value`, `placeholder`, `action` | Text input | | `number` | `id`, `label`, `value`, `action` | Numeric input | | `textarea` | `id`, `label`, `value`, `action` | Multiline input | | `select` | `id`, `label`, `value`, `options`, `multiple`, `clearable`, `action` | Selection control | | `toggle` | `id`, `label`, `value`, `color`, `action` | Boolean switch | | `checkbox` | `id`, `label`, `value`, `color`, `action` | Boolean checkbox | | `button` | `label`, `icon`, `disabled`, `appearance`, `action` | Explicit action | Common layout properties are `grow`, `columns` from 1-12, and `gap` using `none`, `xs`, `sm`, `md`, `lg`, or `xl`. Select options may be primitive values or `{ "label": "Display", "value": "stored-value" }` objects. ## Conditions Add `visibleWhen` to any node. Use one comparison with a bound `path`. ```json { "visibleWhen": { "path": "$item.status", "in": ["PENDING", "ASSIGNED"] } } ``` Supported comparisons are `equals`, `notEquals`, and `in`. With no comparison, visibility follows the truthiness of `path`. ## Actions Controls use the same action envelope. The CAD creates an event containing the action ID, resolved values, actor, panel, instance, and server. ```json { "type": "toggle", "id": "door-locked", "label": "Locked", "value": "$item.locked", "action": { "id": "door.set-locked", "confirm": "Change this door?", "values": { "doorId": "$item.id", "locked": "$value" } } } ``` `confirm` is optional. It displays a CAD confirmation dialog before the action is queued. ## Repeated Collections Set `source` to a state array. Child nodes can bind to the current `$item`. ```json { "type": "repeat", "source": "$state.doors", "emptyText": "No doors reported", "layout": "grid", "minItemWidth": 245, "gap": "sm", "children": [] } ``` `minItemWidth` accepts 120-800 pixels. The grid automatically changes its column count with the panel width. ### Search Search is local to the CAD client and does not call the API. ```json { "search": { "placeholder": "Search doors", "fields": ["name", "facility", "status"] } } ``` If `fields` is omitted, primitive properties on the item are searched. ### Sort Each option has a stable `value` and ordered rules. A rule can use `direction` (`asc` or `desc`) or an explicit `order` array. ```json { "sort": { "label": "Order", "default": "priority", "options": [ { "label": "Pending first", "value": "priority", "rules": [ { "path": "status", "order": ["PENDING", "ASSIGNED", "COMPLETED"] }, { "path": "createdAt", "direction": "asc" } ] } ] } } ``` ## Theme-Safe Styling Arbitrary CSS is not accepted. This keeps community panels safe and compatible with every CAD theme. `appearance` supports `positive`, `negative`, `warning`, `primary`, `info`, `muted`, and `neutral`. Color fields and `style.backgroundColor`, `style.borderColor`, or `style.color` must use one of these v2 token names: `amber`, `amber-text`, `background`, `blue`, `blue-text`, `component-border`, `foreground`, `foreground-light`, `icon`, `positive`, `positive-text`, `primary`, `primary-faded`, `primary-text`, `text-inverse`, `text-primary`, `text-subtitle`, or `text-title`. Allowed non-color style properties are `borderRadius`, `borderStyle`, `borderWidth`, `fontSize`, `fontWeight`, `margin`, `maxHeight`, `minHeight`, `opacity`, `padding`, and `textAlign`. Built-in animations are `pulse-negative`, `pulse-warning`, and `pulse-positive`. Animation values may be bound to state. ## Sounds Sound URLs must use HTTPS. Local paths and localhost HTTP are accepted while developing. Browser autoplay rules may require the user to interact with the CAD before audio can play. ```json { "sounds": [ { "id": "alarm-active", "url": "https://s3.sonorancad.com/default/examples/demos/fire-alarm-demo.mp3", "volume": 0.7, "maxDurationMs": 8000, "trigger": { "event": "state", "path": "summary.active", "operator": "increased" } } ] } ``` | Property | Rules | | ------------------ | ----------------------------------------------------------------------------- | | `id` | Stable sound identifier | | `url` | HTTPS audio URL | | `volume` | 0-1; default `0.7` | | `maxDurationMs` | 1,000-30,000; default `10,000` | | `trigger.event` | `state` or `action` | | `trigger.path` | Dot path in state; omit to compare complete state | | `trigger.operator` | `changed`, `increased`, `decreased`, `equals`, `becameTrue`, or `becameFalse` | | `trigger.value` | Comparison value for `equals` | | `trigger.actionId` | Optional action ID filter for action sounds | State sounds compare the prior and current values and do not play on initial load. Duplicate playback is suppressed for 500 ms. --- # Agent Instructions This documentation is published with GitBook. GitBook is the documentation platform designed so that both humans and AI agents can read, navigate, and reason over technical content effectively. Learn more at gitbook.com. ## Querying This Documentation If you need additional information that is not directly available in this page, you can query the documentation dynamically by asking a question. Perform an HTTP GET request on the current page URL with the `ask` query parameter, and the optional `goal` query parameter: ``` GET https://docs.sonoransoftware.com/cad/api-integration/api-endpoints-v2/integration-panels/manifest-reference.md?ask=&goal= ``` `ask` is the immediate question: it should be specific, self-contained, and written in natural language. `goal` is optional and describes the broader end goal you are ultimately trying to accomplish on behalf of the user. GitBook uses it to tailor the answer towards what is most useful for that goal. The response will contain a direct answer to the question and relevant excerpts and sources from the documentation. Use this mechanism when the answer is not explicitly present in the current page, you need clarification or additional context, or you want to retrieve related documentation sections.
